Keep Your Home Powered During Outages
Turn solar panels and a 48V battery into reliable 120V backup power for your refrigerator, lights, Wi-Fi, laptops, TV, and daily essentials.
6500W Pure Sine Wave Output / Dual MPPT 9000W PV Input / ≤10ms Typical Transfer / UL 1741 Certified
Important Note: One unit supports 120V output. 120/240V split-phase setup requires 2 compatible units.
Small Note: Battery required for backup power. Batteries and solar panels are sold separately unless included in a bundle.
Keep Essential Power Running During Outages
The EASUN SGR-6.5KW-U helps power your most important 120V home loads—from refrigerators, lights, and Wi-Fi to laptops, TVs, microwaves, and security devices—through a reliable 48V battery backup system with 6500W rated output and 12000VA peak power.
Power Outages, Rising Bills, and Solar Waste Are Real Problems
Across the U.S., homeowners are dealing with more frequent outages, higher electricity costs, and increased demand for reliable backup power. Storms, grid failures, extreme weather, and utility interruptions can shut down the devices your family depends on every day.
Solar panels help, but without the right inverter and battery system, daytime solar power may not be available when you need it most — at night, during outages, or when grid power becomes unstable.
The EASUN SGR-6.5KW-U helps solve these problems by combining solar charging, battery storage control, and pure sine wave backup output in one compact 48V hybrid inverter.
Power Outages
Keep essential home loads running when utility power fails.
Unused Solar Energy
Store daytime solar energy in a battery for evening use and backup situations.
High Utility Dependence
Use solar and battery power more intelligently to reduce reliance on the grid.
Future Expansion Needs
Start with one unit for 120V backup loads and expand later as your system grows.
What Do You Need for Home Backup?
A working backup power system usually includes more than just an inverter. To build a reliable home backup system, you will typically need these core components.
1. Hybrid Inverter
The inverter converts 48V battery power into usable 120V AC power for home loads. It also manages solar charging, AC charging, output priority, and operating modes.
2. 48V Battery Bank
The battery stores energy for outages, nighttime use, and backup operation. Battery capacity determines how long your loads can run.
3. Solar Panels
Solar panels recharge your battery during the day and help reduce grid dependence. The SGR-6.5KW-U supports up to 9000W total PV input through dual MPPT channels.
4. Professional Installation
Professional installation is recommended for safe wiring, correct system configuration, battery connection, PV string design, and local electrical code compliance.
Reminder: Battery and solar panels are sold separately unless included in a specific bundle.
Built for U.S. 120V Home Backup
The SGR-6.5KW-U is designed for U.S. home backup applications with 120V output from a single unit. This makes it suitable for common household backup loads such as refrigerators, lights, routers, TVs, laptops, microwaves, and small appliances.
Important: A single SGR-6.5KW-U does not provide 240V output by itself. For 240V appliances, use 2 compatible units for split-phase 120/240V output.
Charge Faster with Dual MPPT Solar Input
The SGR-6.5KW-U includes two independent MPPT solar inputs, allowing installers to connect two PV strings separately. This helps improve flexibility for different roof layouts, panel orientations, and solar array designs.
9000W Total PV Input
Connect up to PV1 4500W + PV2 4500W = 9000W total PV input.
300Vdc Max PV Open-Circuit Voltage
Supports higher-voltage solar string design within the official manual limits.
90–260Vdc MPPT Range
Helps the inverter track solar production efficiently throughout the day.
Charge While Supporting Loads
Solar input can help charge the battery while supporting connected household loads, depending on available PV power and selected operating mode.
Installation Note: Proper PV string design must follow the official manual limits for voltage, current, wiring, and protection.
One Unit. Three Core Functions.
The SGR-6.5KW-U combines a pure sine wave inverter, solar charge controller, and AC battery charger in one compact wall-mounted system.
Pure Sine Wave Inverter
Provides clean and stable AC power for appliances, electronics, refrigerators, routers, TVs, computers, and sensitive devices.
- 6500W rated output
- 12000VA peak power
Solar Charge Controller
Dual MPPT inputs help capture solar energy from your PV array and charge the connected battery bank.
AC Battery Charger
Charge your battery from utility power or generator input when solar power is limited.
- Max. 120A AC charging current
Hybrid Charging
Use solar and AC charging together for faster battery recovery when needed.
- Max. 150A total charging current
Smarter Charging for Every Backup Scenario
Choose the right power strategy for your home. Use solar first to save more energy, rely on grid power when stability matters, or combine solar and grid charging for faster battery recovery before storms, outages, or low-solar days.
Modes: Solar Only / PV Priority / Mains Priority / Hybrid Charging
Charging Capability: Max. 120A AC charging / Max. 150A PV charging / Max. 150A total charging current.
Easy LCD Control and Real-Time Monitoring
The built-in LCD screen makes it easier for users and installers to view system information, adjust key settings, and select operating modes directly from the inverter.
Real-Time Data Monitoring
View system status, voltage, battery information, charging status, load condition, and fault alerts.
Parameter Settings
Adjust battery type, charging current, output priority, charging priority, and other key system settings.
Mode Selection
Switch between operating modes based on your backup needs, solar production, battery status, and grid conditions.
Clear System Status
The LCD display provides a direct overview of inverter operation without requiring complicated external tools.
Help Keep Sensitive Devices Running Smoothly
When utility power changes or fails, sensitive devices can restart, flicker, or shut down unexpectedly. The SGR-6.5KW-U provides a typical ≤10ms transfer time, helping reduce interruptions for routers, computers, TVs, home office equipment, and other sensitive electronics.
Typical ≤10ms Transfer
Fast switching helps improve backup continuity when grid power changes.
Certified for U.S. Solar Backup Applications
UL 1741 Certified and FCC Part 15 Class B.
Multiple Protection Functions
- Overload protection
- Short-circuit protection
- Overcurrent protection
- Overheating protection
- Battery over-voltage protection
System Protection Coverage
- Battery under-voltage protection
- PV reverse polarity protection
- AC reverse protection
- Bypass overcurrent protection
- Parallel communication protection
Note: Protection behavior depends on correct installation, wiring, battery settings, and system configuration.
Flexible 48V Battery Compatibility
Supports lead-acid, GEL, and LFP lithium batteries, plus user-defined battery settings. Compatible lithium batteries can connect through RS485 BMS communication for coordinated charging and battery management.
Note: BMS communication depends on the battery model and supported protocol.
Quiet Operation for Garage and Utility Room Installation
The SGR-6.5KW-U uses forced-air cooling with intelligent fan control to help maintain stable performance under different load and charging conditions.
Installation Reminder: Install the inverter in a suitable location with proper ventilation, clearance, wiring protection, and code-compliant electrical work.
Start Small. Expand When You Need More.
The SGR-6.5KW-U parallel model allows users to start with essential 120V backup and expand the system later as power needs grow.
1 Unit
Best for essential 120V home backup loads.
- 120V essential home backup
2 Units
Required for 120/240V split-phase configuration.
- 120/240V split-phase setup
Up to 6 Units
Supports larger system expansion.
Home Backup
Keep essential household devices running during outages.
Off-Grid Villas
Build a larger solar backup system for remote or independent homes.
Workshops
Support selected tools, lights, chargers, and equipment within system limits.
Agricultural Production
Useful for farms, greenhouse systems, irrigation controls, and remote power needs.
Note: Parallel installation is available on the compatible parallel model and must be configured correctly.
